Power Quality Solution for Commercial Building Industry

Ikonmac’s power quality solutions implemented in a commercial building

Industry Overview

With the rapid development of smart cities, the demand for energy-saving in commercial plazas, residential areas, and public facilities is becoming increasingly profound. While energy-saving equipment is widely used in power distribution systems, it also generates a large amount of harmonic pollution, leading to equipment losses and safety hazards.

Power Quality Issues

Harmonic pollution in commercial plazas, residential areas, and office buildings mainly comes from electronic ballasts in energy-saving lighting and rectifier-type power devices like UPS systems, office equipment, and variable frequency air conditioners. These sources generate 3rd-order, 5th, and 7th-order harmonics, with the harmonic distortion rate in commercial buildings typically ranging from 10-30%.

Power Quality Challenges

Nonlinear loads on-site primarily generate 3rd-order zero-sequence harmonics. Since the vector angles of the 3rd-order harmonic currents are the same, their three-phase vector sum cannot cancel out and instead accumulates on the neutral line, causing the neutral current to exceed twice the phase current. This leads to severe overheating of the neutral wire, rapid aging of its protective rubber insulation, and, in extreme cases, potential fire hazards.

Solution

IKonMac’s Active Harmonic Filter mitigate harmonics from 2nd to 50th order. Commercial buildings primarily generate 3rd, 5th, and 7th-order harmonics, with the 3rd-order being most significant. Single-phase loads can cause three-phase current imbalance.

The IKM-AHF effectively mitigates harmonics and balances three-phase current, improving system power quality and ensuring safe electricity usage. AHFs can be installed in distribution cabinets for centralized mitigation or mounted on walls near distribution boxes for localized solutions.

SUCCESSFUL COMMERCIAL BUILDING CASES

400Amps Active Harmonic Filter

Beijing Beichen Times Tower

600Kvar Static Var Generator

Nanjing Olympic Center

400A Active Harmonic Filter

Shanghai Zhaofeng Plaza

No.	City	Project	Date	Solution
1	Shanghai	World Top Scientists Forum Conference Center Reactive Power Compensation Project	November 2023	SVG
2	Guangdong	Shenzhen ADC Art Exhibition Center Reactive Power Compensation Project	November 2023	SVG
3	Jiangsu	Nanjing Olympic Sports Center Reactive Power Compensation Project	October 2023	SVG
4	Henan	Longhu International Center Reactive Power Compensation Project	August 2023	SVG
5	Shandong	Jinan Western Convention Center Harmonic Treatment Project	May 2020	AHF
6	Beijing	Beijing Zhongguancun Conference Center Harmonic Treatment Project	September 2020	AHF
7	Guangdong	Shenzhen Bay One Conference Center Harmonic Treatment Project	January 2020	AHF
8	Shanghai	Shanghai International Exhibition Center Imbalance Current Treatment Project	September 2019	SVG
9	Shaanxi	SEG International Shopping Center Reactive Power Compensation Project	August 2018	SVG
10	Shandong	Taixing Phoenix Plaza Harmonic Treatment Project	June 2017	AHF
