Power Quality Solution for Hospital Industry

Ikonmac’s power quality solutions implemented in a hospital setting

Industry Overview

The medical industry, particularly hospitals, has seen significant advancements with the widespread use of electronic medical equipment. However, these devices often generate substantial harmonic distortion, which distorts voltage and current waveforms, affecting power supply quality. This can damage electrical systems, shorten equipment lifespan, interfere with critical medical devices, and compromise patient and staff safety.

Power Quality Issues

Hospital power systems supply electricity to medical equipment, lighting, ventilation, computers, and UPS systems. Harmonics primarily come from switching power supplies, electronic ballasts, frequency converters, and rectifiers. Switching power supplies generate 3rd, 5th, and 7th harmonics, while electronic ballasts in lighting produce 3rd-order zero-sequence harmonics. Frequency converters and rectifiers in ventilation and UPS systems generate 5th, 7th, and 11th harmonics. Harmonic distortion in the medical industry typically ranges from 15% to 25%.

Power Quality Challenges

Harmonics-induced voltage fluctuations can affect medical instruments, causing performance issues and inaccurate readings. Power disruptions and grid disturbances pose significant risks to hospitals. Many devices struggle in harmonic-rich environments, which can reduce their lifespan. 3rd-order harmonics accumulate on the neutral line, raising current levels, overheating cables, and potentially causing fires. Specialized harmonic mitigation equipment is crucial.

Solution

IKonMac's IKM-Active Harmonic Filter series can effectively mitigate 2nd to 50th harmonics. The medical industry is primarily affected by 3rd, 5th, 7th, 11th, and 13th harmonics. Additionally, hospitals have a high concentration of single-phase loads, which can lead to unbalanced three-phase currents. To address both harmonics and three-phase imbalance, the IKM-AHF series provides an effective solution, significantly improving power quality and ensuring safe and stable hospital operations.

SUCCESSFUL HOSPITAL CASES

1650Amps Active Harmonic Filter

Chongqing People's Hospital

600Kvar Static Var Generator

Sun Yat-sen University Hospital

No.	City	Project	Date	Solution
1	Chongqing	Chongqing Shapingba District People’s Hospital Harmonic Treatment Project	March 2024	AHF
2	Guangdong	Third Affiliated Hospital of Sun Yat-sen University Reactive Power Compensation Project	March 2024	SVG
3	Zhejiang	Yongkang First People’s Hospital Harmonic Treatment Project	September 2023	AHF
4	Fujian	Fu’an City People’s Hospital Reactive Power Compensation Project	March 2023	SVG
5	Guangdong	Third Affiliated Hospital of Sun Yat-sen University	January 2023	AHF
6	Yunnan	Shizong County Renhe Hospital Reactive Power Compensation Project	December 2022	SVG/AHF
7	Anhui	Linquan County People’s Hospital Harmonic Treatment Project	November 2022	AHF
8	Hunan	Linli County People’s Hospital	November 2022	SVG
9	Liaoning	Dalian Wafangdian Central Hospital Harmonic Treatment Project	October 2022	AHF
10	Shanghai	Shanghai Yibo Hospital Reactive Power Compensation Project	July 2022	SVG

SUCCESSFUL HOSPITAL CASES

1650Amps Active Harmonic Filter

Chongqing People's Hospital

600Kvar Static Var Generator

Sun Yat-sen University Hospital

Date	Project	Solution
Mar 2024	Shapingba District People’s Hospital	AHF
Mar 2024	Hospital of Sun Yat-sen University	SVG
Sep 2023	Yongkang First People’s Hospital	AHF
Mar 2023	Fu’an City People’s Hospital	SVG
Jan 2023	Third Affiliated Hospital	AHF
Dec 2022	Shizong County Renhe Hospital	SVG/AHF
Nov 2022	Linquan County People’s Hospital	AHF
Nov 2022	Linli County People’s Hospital	SVG
Oct 2022	Dalian Wafangdian Central Hospital	AHF
Jul 2022	Shanghai Yibo Hospital	SVG
